Sheet Metal Discs
Series : 1050,1060,1070, 1100,3003, 5052
Temper : O, H12, H14, H16, H18
Thickness : 0.2-10.0 mm
Diameter : 20-1200mm
Application : road sign, cookware, lamp cover
Sheet Metal Discs
Aluminum sheet metal disc is widely used in making aluminum cookware, as aluminum sauce pan, pizza pan and utensils application.
Specification of Sheet Metal Discs:
►Alloy:1050, 1060, 1070, 1100, 3002, 3003, 3004, 5052, 5754, 6061 etc
►Temper: O, H12, H14, H16, H18
►Thickness:0.012" - 0.39" (0.3mm - 10mm)
►Diameter:0.79" - 47.3" (20mm -1200mm)►Surface:Polished, Bright, Anodized
Aluminum Circle Properties
TEMPER | THICKNESS(MM) | TENSILE STRENGTH | ELONGATION(%) |
HO | 0.3-6 | 60-100 | ≥ 20 |
H12 | 0.5-6 | 70-120 | ≥ 4 |
H14 | 0.5-6 | 85-120 | ≥ 2 |
Features of Falt Metal Discs:
Wide range of selection on circles’ size.
Excellent Surface Quality for lighting reflectors.
Excellent in forming, welding and corrosion resistance though lacking the strength
Excellent deep drawing and spinning quality.
We provide heavy gauge circles with thicknesses up to 5mm diameter up to 1200mm, which would meet all your needs.
Anodizing Quality and Deep Drawing Quality which is suitable for cookware as well.
Well-Protected Packing.
Application of Metal Disc Plate:
Our aluminum sheet metal disc can be used in the production of a variety of cookware products,such as for deep drawing, spinning, crafts, Reflector Panel, Traffic Sign, Decorative Products, Conductive Material, Construction Material, Electrical Appliances, etc
Processing of Metal Plate Disc:
